Наука та прогрес транспорту. Вюник Дншропетровського нацюнального унiверситету залiзничного транспорту, 2017, № 6 (72)

UDC 514.182

O. S. DANYLOVA1*, A. S. SHCHERBAK2, A. V. KRASNIUK3

1 Dep. «Graphics», Dnipropetrovsk National University of Railway Transport named after Academician V. Lazaryan, Lazaryan St., 2, Dnipro, Ukraine, 49010, tel. +38 (056) 373 15 59, e-mail diit.geometry@gmail.com, ORCID 0000-0003-1375-0575

2Dep. «Graphics», Dnipropetrovsk National University of Railway Transport named after Academician V. Lazaryan, Lazaryan St., 2, Dnipro, Ukraine, 49010, tel. +38 (056) 373 15 59, pro-f@ukr.net, ORCID 0000-0003-1340-0284

3Dep. «Graphics», Dnipropetrovsk National University of Railway Transport named after Academician V. Lazaryan, Lazaryan St., 2, Dnipro, Ukraine, 49010, tel. +38 (056) 373 15 59, e-mail diit.geometry@gmail.com, ORCID 0000-0002-1400-9992

POINTS ON THE SPHERE SURFACE

Purpose. The extensive use of the computer-aided design system (CAD) in education and industry puts forward new demands on the scope, content and quality of up-to-date descriptive geometry course. The purpose of the work is topicality analysis of traditional descriptive geometry methods for 3D modelling and development of methodological recommendations for its teaching as a subject together with a selected CAD. Methodology. Conclusions about effectiveness and expedience of application of descriptive geometry methods are drawn on the basis of tools analysis and comparison of modern CADs and descriptive geometry for solving problems arising during 3D modelling. Generalization of teaching experience made it possible to give recommendations about optimization of the descriptive geometry course taking into account present-day requirements to professional skills of an engineer. Findings. CADs tools and descriptive geometry methods are compared by way of specific example to give the answer what is more suitable for solving problems arising during 3D modelling. Originality. We presented the methodological recommendations about optimization of descriptive geometry teaching together with a selected CAD. We proposed the conception of a modern textbook on descriptive geometry. First of all, the textbook must describe algorithms for solving problems by means of standard CAD tools exactly in 3D, not on the plane. It is desirable to accompany these algorithms by pictorial images in order to have an opportunity to grasp an idea quickly and implement it through methods of direct modeling in CAD application. We also touched practical problems of students' motivation to ensure high effectiveness of graphical education. Practical value. This paper may be useful mainly for educators in the field of engineering graphics because it raises a vital question 'Descriptive Geometry versus CAD' which now has no definite answer. Topicality and teaching approaches of different solution methods of spatial problems by means of projections is subject of a dispute, taking into account that CAD tools are continuously updated. This paper by way of specific example shows some advantages and limitations of descriptive geometry and CAD, as well as touches the issues of their efficient joint application for teaching.

Keywords: descriptive geometry; CAD; sphere; teaching methods; motivation

Introduction

The surface of a sphere is considered definite, if the position of its centre and the radius are known. The sphere is the surface of revolution. The sphere is also the surface of a full sphere. In computer-aided design systems, a three-dimensional model of a sphere can be constructed by rotating a semicircle around its diameter, i.e. by kinematic way of surface formation. In AutoCAD for construction, there is also a separate command [9], the initial data for which are the coordinates of the centre point of the sphere and the size of its radius - the analytical method.

Purpose

In some cases, there is a need to fit a sphere into the already existing geometry, i.e. to construct the sphere surface when the position of several points on its surface is known, while the centre and radius are unknown. As it is known, for the unambiguous definition of a sphere it is necessary to know the coordinates of at least four noncoplanar points lying on its surface. 3D modelling programs do not have built-in tools for such constructions, and textbooks on descriptive geometry (DG) describe only the kinematic and analytical way of determining the surface. The graphical specification of a second-order surface by points is not

Наука та прогрес транспорту. Вюник Дншропетровського нацюнального унiверситету залiзничного транспорту, 2017, № 6 (72)

a typical way of determining a surface, although it can occur when solving practical problems.

Methodology

As sphere is the geometric locus of points in space equidistant from a point called the sphere centre, then the solution of this problem consists in finding a point equidistant from the four given

values [2]. Thus, with 3D modelling, we come across a separate class of problems, when it is necessary to go from one set of input data (4 points on the sphere surface) to the other (sphere centre and radius). Such problems can be successfully solved by DG methods, and the construction algorithms are used in computer simulation.

Fig. 1. Construction of sphere centre by 4 points (four replacements of projection planes)

Fig. 1 shows one of the possible graphical solutions of this problem using DG methods. There are given four points A, B, C, D in two projections. The found points O1 and O2 are the desired projections of the sphere centre. As you know, you can draw a circle through any three given points.

This circle can be regarded as a parallel of the desired sphere. Then the sphere centre will lie on the perpendicular reconstructed from the centre of the parallel. It is necessary to build two different parallels at given points and restore perpendiculars from

Наука та прогрес транспорту. Вюник Дншропетровського нацюнального унiверситету залiзничного транспорту, 2017, № 6 (72)

their centres. The intersection point of the perpendiculars will be the sphere centre.

On the plane, by using a double replacement of the projection planes, we found the natural value of each of the two planes formed by the given points. Then we constructed the sphere parallels, perpendiculars from their centres, and found the intersection point of these perpendiculars. From the point of view of DG, this method of solving the problem on the plane is not optimal, because there is another

one, which requires fewer graphic. However, this is a simple and understandable way to solve the problem straight forward.

Figures 2 and 3 show the second way of finding the desired sphere centre. We take any three points for belonging to a common parallel and find its centre. Using the fourth point, we construct another parallel and find the sphere centre. Since any of the given points can be taken as the fourth one, there are four possible solutions.

Fig. 2. Construction of sphere centre by 4 points (double replacement of projection planes)

To solve the problem, it is also necessary to replace the projection planes twice. We turn the points C, B and D into a plane, passing through them the intersecting lines CD and the horizontal h. We find the natural value of this plane and construct a circle around the three points C, B, D - projection of the parallel m5. Through the fourth point A, the projection of the second parallel k5 is constructed. On plane P5 both parallels are projected in the form of concentric circles, and on P4 in the form of parallel segments of straight lines. The extreme points of the

projections of parallels 2 and 3 define a circle whose centre coincides with the sphere centre. Points 2 and 3 must be joined by a straight line segment. From the middle of this segment, we restore the perpendicular, which will pass through the sphere centre.

Some 3D modelling programs allow imposing parametric constraints and restrictions on geometric objects. With the help of such tools it is possible to simplify the solution of problems and in general to avoid additional constructions [12].

Наука та прогрес транспорту. Вюник Дншропетровського нацюнального унiверситету залiзничного транспорту, 2017, № 6 (72)

For example, in SolidWorks, to find the sphere centre in a three-dimensional sketch, you can select an arbitrary point and connect it to four specified points with straight line segments. Then you need to select all the lines and define the geometric «equality» relationship between them (Figure 4).

The program will automatically move an arbitrarily chosen point to such a position that all segments become the same length, i.e. it will find the sphere centre - a point equidistant from the four given values.

Fig. 3. Construction of sphere centre by 4 points (double replacement of projection planes), visual image

Next, we need to construct a plane through the centre and any two points, construct a semicircle in this plane and obtain the sphere by the rotation method.

This method cannot be used in AutoCAD and KOMPAS-3D. In KOMPAS-3D, parametric constraints can only be imposed on flat objects in a sketch, and in AutoCAD such geometric dependencies cannot be applied to objects lying in different planes.

Findings

Despite the fact that modern CAD systems are quite a powerful tool, they are not perfect, i.e. do not have tools «for all occasions». Moreover, the effectiveness of their use directly depends on the user's skills, including his geometrical-graphic training. The study of descriptive geometry is one of the most important stages of such training.

In addition to its main purpose of developing spatial thinking, descriptive geometry studies methods of solving the applied tasks. Many of these tasks can be solved by CAD, but one of the areas remaining relevant in DG so far is the solution of tasks that require a transition from one set of initial geometric data to another set of such data needed for modelling [17].

Originality and practical value

The extensive use of CAD in education and industry also puts forward new demands on the scope, content and quality of up-to-date descriptive geometry course. [1, 3, 4-8, 10, 13-16]. Now the user has the ability to solve spatial geometric problems in the virtual three-dimensional space of the program, which makes it possible to avoid cumbersome construction on the projection planes. Therefore, the ideal DG textbook should first of all give

Наука та прогрес транспорту. Вюник Дншропетровського нацюнального унiверситету залiзничного транспорту, 2017, № 6 (72)

algorithms for task solving using the typical CAD tools exactly in 3D, and not on a plane. It is desirable to accompany these algorithms by pictorial images in order to have an opportunity to

grasp an idea quickly and implement it in 3D. Complex constructions on the plane go to the background.

Fig. 4. Specifying the geometric «equality» relationship for straight line segments in SolidWorks

Conclusions

The solution of the problem in the three-dimensional space of the program is a natural process for a man. DG methods for solving spatial problems on a plane were developed when there was simply no other way to obtain a result. These methods are beautiful and elegant and often startle the imagination, but are they needed now, when the result can be achieved by pressing just a few buttons? Of course, we cannot and should not completely abandon the methods of classical DG: there are situations when they are still necessary. But the number of such tasks is getting smaller every year. Modern DG course should, first of all, include algorithms based on methods of direct modelling in 3D space, avoiding projection transformations.

As it is known, DG is considered by most students as a complex subject, for the study of which one needs certain motivation. Many students having acquainted with 3D modelling programs do

not understand what the meaning of studying DG is, «if everything can be built on a computer». Therefore, methodically it makes sense to divide a joint study of DG and engineering computer graphics into two stages.

The first stage: study of the basic capabilities of CAD. At this stage the proposed tasks do not require involvement of DG and are designed to teach a user to apply the main CAD tools. The task of this stage is to give the student a powerful tool and to teach him how to use it. The user should receive positive emotions from the fact that he can build 3D models and receive drawings using computer programs. It is very important that at this stage the student learns to achieve a positive result on his own.

The second stage: the tasks proposed for modelling to the student should require additional constructions, involvement of DG or analytical geometry. For example, such tasks may require a transition from a geometry task with one set of input data to another set that can be implemented

Наука та прогрес транспорту. Вюник Дншропетровського нацюнального ушверситету зашзничного транспорту, 2017, N° 6 (72)

in the relevant CAD. The tasks should contain some of the tasks of DG, which is skillfully woven into the existing geometry. Herewith by the total volume of work and visually the models at this stage can be simpler than the previous ones. A situation is created when a user who knows how to use CAD cannot build a «simpler geometry» [11]. It is necessary to draw from the user an emotional state of excitement, which is characterized by a very strong interest in what is happening and

LIST OF REFERENCE LINKS

1. Иванов, Г. С. Перспективы начертательной геометрии как учебной дисциплины / Г. С. Иванов // Геометрия и графика - 2013. - Т. 1, вып. 1 - С. 26-28. doi: 10.12737/467.

2. Лосев, Н. В. 200 олимпиадных задач по начертательной геометрии : практ. пособие / Н. В. Лосев. -Москва : Высш. шк., 1992. - 144 с.

3. Междисциплинарные связи начертательной геометрии и смежных разделов высшей математики / И. М. Дмитриева, Г. С. Иванов, В. И. Серегин, К. А. Муравьев // Геометрия и графика. - 2013. - Т. 1, вып. 3. - С. 8-12. doi: 10.12737/2124.

4. Сальков, Н. А. Геометрическое моделирование и начертательная геометрия / Н. А. Сальков // Геометрия и графика. - 2016. - Т. 4, вып. 4. - С. 31-40. doi: 10.12737/22841.

5. Сальков, Н. А. Место начертательной геометрии в системе геометрического образования технических вузов / Н. А. Сальков // Геометрия и графика. - 2016. - Т. 4, вып. 3. - С. 53-61. doi: 10.12737/21534.

6. Сальков, Н. А. Начертательная геометрия — база для компьютерной графики / Н. А. Сальков // Геометрия и графика. - 2016. - Т. 4, вып. 2. - С. 37-47. doi: 10.12737/19832.

7. Хейфец, А. Л. Начертательная геометрия как «бег в мешках» / А. Л. Хейфец // Проблемы качества графической подготовки студентов в техническом ВУЗе: традиции и инновации : материалы V Междунар. науч.-практ. интернет-конф. - Пермь, 2015. - Т. 1. - С. 298-325.

8. Хейфец, А. Л. Реорганизация курса начертательной геометрии как актуальная задача развития кафедр графики / А. Л. Хейфец // Геометрия и графика. - 2013. - Т. 1, вып. 2. - С. 21-23. doi: 10.12737/781.

9. Autodesk AutoCAD Help [Electronic resource]. - Available at: http://help.autodesk.com/view/ACD/2016/ENU/. - Title from screen. - Accessed : 02.10.2017.

10. Bokan, N. Computer-Aided Teaching of Descriptive Geometry / N. Bokan, M. Ljucovic, S. Vukmirovic // Journal for Geometry and Graphics. - 2009. - Vol. 13, No. 2. - P. 221-229.

11. Danilov, E. Descriptive Geometry for CAD Users: Ribs Construction / E. Danilov // Journal for Geometry and Graphics. - 2014. - Vol. 18, No. 1. - P. 115-124.

12. SolidWorks Web Help [Electronic resource]. - Available at: http://help.solidworks.com/. - Title from screen. -Accessed : 02.10.2017.

13. Suzuki, K. Application of descriptive geometry procedures in solving spatial problems with feature and parametric modelling 3D-CAD / K. Suzuki, H-P. Schroecker // Proc. of the 13th ICGG. - Dresden, Germany, 2008. - Vol. II. - P. 1-8.

14. Suzuki, K. Introduction to 3D-CAD/CG - Learning geometry and graphics through Inventor and 3ds Max. -2nd ed. [in Japanese] / K. Suzuki, Y. Yokoyama, T. Kanai. - Tokyo, Japan, 2012.

15. Suzuki, K. Significance of traditional geometry in teaching and learning graphic science / K. Suzuki // CADDM: computer aided drafting, design and manufacturing. - 2013. - Vol. 23/3. - P. 49-55.

16. Suzuki, K. Traditional Descriptive Geometry Education in the 3D-CAD/CG Era / K. Suzuki // Journal for Geometry and Graphics. - 2014. - Vol. 18, No. 2. - P. 249-258.

17. Zsombor-Murray, P. A Cylinder of Revolution on Five Points / P. Zsombor-Murray, S. El Fashny // Journal for Geometry and Graphics. - 2006. - Vol. 10, No. 2. - P. 207-213.

a persistent desire to continue. It is very important to give the student time to think independently before explaining the solution. Perhaps this is the most important point of learning. It makes sense to give clues that will indicate the desired direction of the solution search. The task of the teacher is to show the student DG place and possibilities for solving the problems that arise during 3D modelling.

Наука та прогрес транспорту. Вюник Дншропетровського нацюнального унiверситету залiзничного транспорту, 2017, № 6 (72)

О. С. ДАНИЛОВА1*, А. С. ЩЕРБАК2, А. В. КРАСНЮК3

1 Каф. «Графжа», Дншропетровський нацюнальний ушверситет зал1зничного транспорту 1мет академжа В. Лазаряна, вул. Лазаряна, 2, Дншро, Укра!на, 49010, тел. +38 (056) 373 15 59, ел. пошта diit.geometry@gmail.com, ORCID 0000-0003-1375-0575

2Каф. «Графжа», Дншропетровський нацюнальний утверситет затзничного транспорту 1мет академжа В. Лазаряна, вул. Лазаряна, 2, Дншро, Укра!на, 49010, тел. +38 (056) 373 15 59, ел. пошта pro-f@ukr.net, ORCID 0000-0003-1340-0284 3Каф. «Графжа», Дншропетровський нацюнальний утверситет затзничного транспорту 1мет академжа В. Лазаряна, вул. Лазаряна, 2, Дншро, Укра!на, 49010, тел. +38 (056) 373 15 59, ел. пошта diit.geometry@gmail.com, ORCID 0000-0002-1400-9992

ТОЧКИ НА ПОВЕРХН1 СФЕРИ

Мета. Широке застосування системи автоматизованого проектування (САПР) в навчальному процеа та на виробнищга висувае нов1 вимоги до об'ему, зм1сту й якост1 викладання сучасного курсу нарисно! геометри. Метою роботи е анал1з актуальносп метод1в класично! нарисно! геометри для задач геометричного мо-делювання та розробка методичних рекомендацш Г! викладання як навчально! дисциплши спшьно з обраною САПР. Методика. Висновки про ефектившсть та доцшьшсть використання метод1в нарисно!' геометри зроблет на основ1 анал1зу й пор1вняння можливостей сучасних САПР та нарисно! геометри для виршення питань, як1 виникають у процеа тривим1рного моделювання. Узагальнення досвщу викладання граф1чних дисциплш дозволило дати рекомендаци щодо оптим1зацп викладання курсу нарисно! геометри з урахуван-ням сучасних вимог до квал1ф1каци 1нженера. Результати. На конкретному приклад1 проведено пор1вняння можливостей САПР та метод1в нарисно! геометри для виршення проблем, як1 виникають при геометрично-му моделюванш. Наукова новизна. Надаш методичт рекомендацп вщносно оргашзаци та оптим1заци викладання курсу нарисно! геометри спшьно з обраною САПР. Запропонована концепщя сучасного тдручни-ка з нарисно! геометри, який, перш за все, повинен давати алгоритми для виршення задач типовими шстру-ментами САПР саме в 3D, а не на площиш. Бажано, щоб щ алгоритми супроводжувалися наочними зобра-женнями, як1 б дозволяли швидко вловити щею та реал1зувати !! методами прямого моделювання у середовищ1 програми тривим1рного моделювання. Розглянуп практичт питання мотиваци студенпв при вивченш нарисно! геометри. Практична значимкть. Дана робота, насамперед, буде щкава викладачам граф1чних дисциплш, так як порушуе актуальне питання «нарисна геометр1я проти САПР», на яке зараз не-мае однозначно! вщповщ. Актуальшсть та спос1б викладання тих або шших метод1в виршення просторо-вих задач за допомогою проекцн на площиш, при постшно зростаючих можливостях прямого 3D моделювання засобами САПР, е предметом обговорення та суперечок. Дана робота на приклад1 демонструе можли-вост1 й обмеження нарисно! геометри та САПР, а також торкаеться питань ефективносл !х спшьного викладання.

Ключовi слова: нарисна геометр1я; САПР; сфера; методика викладання; мотиващя О. С. ДАНИЛОВА1*, А. С. ЩЕРБАК2, А. В. КРАСНЮК3

1 Каф. «Графика», Днепропетровский национальный университет железнодорожного транспорта имени академика В. Лазаряна, ул. Лазаряна, 2, Днипро, Украина, 49010, тел. +38 (056) 373 15 59, эл. почта diit.geometry@gmail.com, ORCID 0000-0003-1375-0575

2Каф. «Графика», Днепропетровский национальный университет железнодорожного транспорта имени академика В. Лазаряна, ул. Лазаряна, 2, Днипро, Украина, 49010, тел. +38 (056) 373 15 59, эл. почта pro-f@ukr.net, ORCID 0000-0003-1340-0284

3Каф. «Графика», Днепропетровский национальный университет железнодорожного транспорта имени академика В. Лазаряна, ул. Лазаряна, 2, Днипро, Украина, 49010, тел. +38 (056) 373 15 59, эл. почта diit.geometry@gmail.com, ORCID 0000-0002-1400-9992

ТОЧКИ НА ПОВЕРХНОСТИ СФЕРЫ

Цель. Широкое использование системы автоматизированного проектирования (САПР) в учебном процессе и на производстве выдвигает новые требования к объему, содержанию и качеству преподавания современного курса начертательной геометрии. Целью работы является анализ актуальности методов классической начертательной геометрии для задач геометрического моделирования и разработка методических

Наука та прогрес транспорту. Вюник Дншропетровського нацюнального ушверситету зашзничного транспорту, 2017, № 6 (72)

рекомендаций её преподавания как учебной дисциплины совместно с выбранной САПР. Методика. Выводы об эффективности и целесообразности применения методов начертательной геометрии сделаны на основе анализа, сравнения возможностей современных САПР и начертательной геометрии для решения вопросов, возникающих в процессе трехмерного моделирования. Обобщение опыта преподавания графических дисциплин позволило дать рекомендации по оптимизации преподавания курса начертательной геометрии с учетом современных требований к квалификации инженера. Результаты. На конкретном примере проведено сравнение возможностей САПР и методов начертательной геометрии для решения проблем, возникающих при геометрическом моделировании. Научная новизна. Даны методические рекомендации относительно организации и оптимизации преподавания курса начертательной геометрии совместно с выбранной САПР. Предложена концепция современного учебника по начертательной геометрии, который, прежде всего, должен давать алгоритмы для решения задачи типовыми инструментами САПР именно в 3D, а не на плоскости. Желательно, чтобы эти алгоритмы сопровождались наглядными изображениями, позволяющими быстро уловить идею и реализовать её методами прямого моделирования в среде программы трехмерного моделирования. Затронуты практические вопросы мотивации студентов при изучении начертательной геометрии. Практическая значимость. Данная работа, прежде всего, будет интересна преподавателям графических дисциплин, т. к. поднимает актуальный вопрос «начертательная геометрия против САПР», на который сейчас нет однозначного ответа. Актуальность и способ преподавания тех или иных методов решения пространственных задач с помощью проекций на плоскости, при постоянно растущих возможностях прямого 3D моделирования средствами САПР, является предметом обсуждения и споров. Данная работа на примере показывает возможности и ограничения начертательной геометрии и САПР, а также касается вопросов эффективности их совместного преподавания.

Ключевые слова: начертательная геометрия; САПР; сфера; методика преподавания; мотивация

REFERENCES

1. Ivanov, G. (2013). Descriptive geometry prospects as educational subject. Geometry & Graphics, 7(1), 26-28. doi: 10.12737/467. (in Russian)

2. Losev, N. V. (1992). 200 olimpiadnykh zadach po nachertatelnoy geometrii: prakticheskoye posobiye. Moscow: Vysshaya shkola. (in Russian)

3. Dmitrieva, I., Ivanov, G., Seregin, V., & Muravev, K. (2013). Interdisciplinary connections of descriptive geometry and related sections of higher mathematics. Geometry & Graphics, 7(3), 8-12. doi: 10.12737/2124. (in Russian)

4. Sal'kov, N. (2016). Geometric Simulation and Descriptive Geometry. Geometry & Graphics, 4(4), 31-40. doi: 10.12737/22841. (in Russian)

5. Salkov, N. (2016). Place of Descriptive Geometry in the System of Geometric Education of Technical Universities. Geometry & Graphics, 4(3), 53-61. doi: 10.12737/21534. (in Russian)

6. Sal'kov, N. (2016). Descriptive Geometry - the Base of Computer Graphics. Geometry & Graphics, 4(2), 3747. doi: 10.12737/19832. (in Russian)

7. Kheyfets, A. L. (2015). Nachertatelnaya geometriya kak «beg v meshkakh». Problemy kachestva graficheskoy podgotovki studentov v tekhnicheskom VUZe: traditsii i innovatsii. Proceedings of the Vth International Scientific and Practical Internet Conference. Perm, 7, 298-325. (in Russian)

8. Kheyfets, A. (2013). Descriptive geometry course reorganization as the actual task of graphics chairs development. Geometry & Graphics, 7(2), 21-23. doi: 10.12737/781. (in Russian)

9. Autodesk AutoCAD Help (2016). Retrieved from: http://help.autodesk.com/view/ACD/2016/ENU/. (in English)

10. Bokan, N., Ljucovic, M., & Vukmirovic, S. (2009). Computer-Aided Teaching of Descriptive Geometry. Journal for Geometry and Graphics, 73(2), 221-229. (in English)

11. Danilov, E. (2014). Descriptive Geometry for CAD Users: Ribs Construction. Journal for Geometry and Graphics, 78(1), 115-124. (in English)

12. SolidWorks Web Help. Retrived from: http://help.solidworks.com/. (in English)

13. Suzuki, K., & Schroecker, H-P (2008). Application of descriptive geometry procedures in solving spatial problems with feature and parametric modelling 3D-CAD. Proceedings of the 73th International Conference on Geometry and Graphics (ICGG). Dresden, August 4-70, 2008, Germany, II, 1-8. (in English)

iНе можете найти то, что вам нужно? Попробуйте сервис подбора литературы.

14. Suzuki, K., Yokoyama, Y., & Kanai T. (2012). Introduction to 3D-CAD/CG - Learning geometry and graphics through Inventor and 3ds Max-2nd edition. [M]. Saiensu, Tokyo, Japan. (in Japanese)

HayKa Ta nporpec TpaHcnopTy. BicHHK flmnponeTpoBChKoro Ha^oH&ihHoro yrnBepcHTeTy 3&m3HH^Horo TpaHcnopTy, 2017, № 6 (72)

15. Suzuki, K. Significance of traditional geometry in teaching and learning graphic science (2013). CADDM: Computer Aided Drafting, Design and Manufacturing, 23/3, 49-55. (in English)

16. Suzuki, K. (2014). Traditional Descriptive Geometry Education in the 3D-CAD/CG Era. Journal for Geometry and Graphics, 18(2), 249-258. (in English)

17. Zsombor-Murray, P., & S. El Fashny (2006). A Cylinder of Revolution on Five Points. Journal for Geometry and Graphics, 10(2), 207-213. (in English)

Prof. V. D. Petrenko, Dr. Sc. (Techn.) (Ukraine); Prof. S. S. Tyshchenko, Dr. Sc. (Techn.) (Ukraine) recommended this article to be published

Received: Aug. 01, 2017 Accessed: Nov. 03, 2017
